Barbed wire fencing
barbed wire fence
1.Barb Length:10-65mm
2.Reference NO.:BTO-22,BTO-65
3.Wire Dia.:2.5mm
4.ISO9001
1.Material :Galvanized steel sheet and wire or Stainless steel sheet and wire.
2.Type of Razor barbed wire:Crossed razor barbed wire;Straight razor barbed wire;
Single Coil barbed wire ;Concertina razor barbed wire, etc.
3.Features:Razor barbed wire mesh is a new kind of protective fencing with such
advantages as beautiful appearance, economical cost and practicality ,and convenient construction.
4.Application:It plays the role of protection in mines, gardens and apartments,frontier
and sentry defence ,and enclosure of prisons
Galvanized Razor Barbed Wire Specification(mm) |
|||||
Types |
Thickness |
Wire Dia. |
Barb Length |
Barb Width |
Barb Spacing |
BTO-10 |
0.5±0.05 |
2.5±0.1 |
10±1 |
13±1 |
26±1 |
BTO-12 |
0.5±0.05 |
2.5±0.1 |
12±1 |
15±1 |
26±1 |
BTO-18 |
0.5±0.05 |
2.5±0.1 |
18±1 |
15±1 |
33±1 |
BTO-22 |
0.5±0.05 |
2.5±0.1 |
22±1 |
15±1 |
34±1 |
BTO-28 |
0.5±0.05 |
2.5 |
28 |
15 |
45±1 |
BTO-30 |
0.5±0.05 |
2.5 |
30 |
18 |
45±1 |
CBT-60 |
0.6±0.05 |
2.5±0.1 |
60±2 |
32±1 |
100±2 |
CBT-65 |
0.6±0.05 |
2.5±0.1 |
65±2 |
21±1 |
100±2 |
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
450mm |
33 |
8M |
CBT-65 |
Single coil |
500mm |
41 |
10M |
CBT-65 |
Single coil |
700mm |
41 |
10M |
CBT-65 |
Single coil |
960mm |
53 |
13M |
CBT-65 |
Single coil |
500mm |
102 |
16M |
BTO-10.15.22 |
Cross type |
600mm |
86 |
14M |
BTO-10.15.22 |
Cross type |
700mm |
72 |
12M |
BTO-10.15.22 |
Cross type |
800mm |
64 |
10M |
BTO-10.15.22 |
Cross type |
960mm |
52 |
9M |
BTO-10.15.22 |
Cross type |
Razor wire fence specification |
||
Razor Wire Fence Size |
Mesh Aperture |
Razor blade |
1.8mX3m |
30X15 15X7.5 |
BTO-12 BTO-18 BTO-22 CBT-65 |
1.8mX6m |
30X15 15X7.5 |
BTO-12 BTO-18 BTO-22 CBT-65 |
1.8mXm9 |
30X15 15X7.5 |
BTO-12 BTO-18 BTO-22 CBT-65 |
1.8mX12m |
30X15 15X7.5 |
BTO-12 BTO-18 BTO-22 CBT-65 |
1.8mX15m |
30X15 15X7.5 |
BTO-12 BTO-18 BTO-22 CBT-65 |
